Kenex Overhead Shield & Lamp 350/45UL

A robust, highly stable 40 cm x 50 cm overhead shield with 2.0 mm equivalent lead glass for effective protection to the upper body, and a 130F examination lamp with 50,000 Lux and a colour rendering index Ra96.

Download PDFDownload advanced Model PDF

Description

Kenex Overhead Shield and Lamp 350/45UL

A robust, highly stable 40 cm x 50 cm shield with 2.0 mm equivalent lead glass (@150 kV) for effective protection to the upper body, it also includes a 130F examination lamp with 50,000 Lux and a colour rendering index Ra96.

Key Features:

  • The robust yoke assembly provides stability and protection to the window
  • The shield is fitted with a 0.5 mm Pb equivalent flexible curtain which is suspended beneath to further reduce scatter radiation
  • The shield assembly connects to a two-part suspension arm, supported by a ceiling column
  • Standard ceiling column length is 80 cm (other lengths available)
  • A second mounting position on the column is used to support a suspension arm and examination lamp
  • The 130F lamp provides effective illumination for the practitioner with 50,000 Lux and a colour rendering index Ra96
  •  The lamp is supplied with a detachable sterilizable handle as standard
  • The ceiling column can be statically mounted to the ceiling or attached to a movable carriage in a ceiling track
  • Optional installation aid #300/P/004 can be used to attach a column to Unistrut rails (or equivalent) in a suspended ceiling
